| Name: | HN-40A Manual corner pasting machine |
|---|---|
| Machine model: | HN-40A |
| Min box size: | 40*40*10mm |
| Working speed: | 20-40pcs/min |
| Motor power: | 220V/0.4Kw |
| Machine dimension: | L1450*W300*H600mm |
| Machine weight: | 150Kg |
| Inquiry |
Product Description
The manual corner pasting machine is applied to pasting the hot melt tape on die cutted or grooved cardboard. It is core step for rigid box making. Which will bring high strength for the box. Ensure the box not easy broken during shipment. This machine has applied the motor to driving the tape feeding and pressing. PVC tape, paper tape and kraft tape is OK with this machine. It is the most popular model on the market.
Features
Time relay function, which can bring longer heating for tape. Such as thicker paper tape.
Tape length adjustable. 0-30mm,
Min pasting size 40*40*10mm.
